C Bracing Section Roll Forming Machine
The C bracing section roll forming machine, also named C beam roll forming machine, is developed to produce high-quality C-profiles used for supporting the upright racks and shelving panels at the side of the warehouse pallet racking system. As a crucial part of a complete heavy duty rack roll forming machine setup, this equipment provides the lateral stability required for industrial storage.
Our intelligent C bracing section roll forming machine could make various sizes of C-beams according to the specific rack system requirements, with material thickness normally ranging from 1.5mm to 1.8mm. The entire production process, including uncoiling, feeding, roll forming, punching, and cutting, can be automatically realized on one efficient line. This machine is often used in conjunction with a rack column roll forming machine to create the essential structural components of a racking frame.
Beyond the C bracing section roll forming machine, we offer a comprehensive range of heavy duty rack roll forming machine solutions, such as step beam, box beam, and shelf panel roll formers. All these are vital components of a professional pallet racking system. At Wuxi Sunway Machinery Co., Ltd., we are able to manufacture specialized equipment like the rack column roll forming machine to meet the diverse needs of the global logistics industry.
We make different solutions according to customers’ drawing, tolerance, and budget, offering professional one-to-one service. Whether you require a standalone C bracing section roll forming machine or a multi-functional heavy duty rack roll forming machine, the quality of SUNWAY Machinery will ensure you obtain perfectly functional profiles. Our expertise in rack column roll forming machine technology ensures that every bracing and column fits with high precision.
| C Bracing Section Roll Forming Machine | ||
| Machinable Material | A) Galvanized Coil B) PPGI, PPGL C) Cold-rolled Steel D) Carbon Steel | Thickness(MM): 1.5-1.8 as per customer |
| Yield Strength | 250 - 350 Mpa | |
| Tensil Stress | 350 Mpa-500 Mpa | |
| Nominal Forming Speed(M/Min) | 10-15 | *Or According To Your Requirment |
| Forming Station | About 14 | *According To Your Profile Drawings |
| Decoiler | Manual Decoiler | *Hydraulic Decoiler (Optional) |
| Driving System | Chain Drive | *Gearbox Drive (Optional) |
| Machine Structure | Steel Plates Welded | * Cast Iron Stands (Optional) |
| Rollers’ Material | GCr 15 | *Cr12Mov (Optional) |
| Cutting System | Hydraulic Pre-cut | |
| Punching System | Hydraulic Punching | |
| Frequency Changer Brand | Yaskawa | *Siemens (Optional) |
| Power Supply | 380V 50Hz | *Or According To Your Requirment |
| Machine Color | Industrial Blue | *Or According To Your Requirment |
Application & Real-World Projects
The warehouse installations below demonstrate the structural strength provided byprofiles from our c bracing section roll forming machine. In any large-scale facility, the heavy duty rack roll forming machine technology ensures that the bracing and the components from the rack column roll forming machine work together to maintain maximum load capacity. SUNWAY's precision-engineered solutions provide the reliabilityshown in these professional storage systems.
